LiDAR Scanners
2D TOF LiDAR for AGV obstacle avoidance, navigation, mapping and perimeter security, 5–100 m.
Choose a Scanner by the Result Your Controller Needs
Separate a safety protective field from ordinary obstacle detection and navigation data before comparing distance. The catalogue includes safety scanning, configurable discrete-output devices and measurement/navigation scanners. A long maximum range or a software stop zone does not turn a measuring scanner into a safety device.
Compare 10 LiDAR Scanners Series
DLD-100D Single-Line TOF Scanning LiDAR
Single-line TOF scanning LiDAR with up to 100 m range, model-dependent 280°/360° coverage, and a 100 Hz / 0.32° DLD-100DP option.
DLD-50D 2D TOF LiDAR for Navigation & Mapping (50 m)
50 m-range 2D TOF LiDAR for mobile robot navigation and mapping — ±20 mm repeatability, 280° FoV, Ethernet output.
DLD-50G 2D Single-line LiDAR (Diffuse-remission Measuring Type)
2D single-line laser scanner measuring diffuse-remission distance off natural surfaces, no reflector needed.
DLD05A3 2D TOF Obstacle-avoidance LiDAR (5 m)
2D TOF LiDAR with NPN/PNP switching outputs that wires like a photoelectric sensor — no protocol stack, no SDK.
DLD20A5-5N / DLD20A5-5P 2D TOF Obstacle-avoidance LiDAR (20 m)
20 m 2D TOF LiDAR with pure NPN/PNP discrete outputs — wires straight into a PLC, no protocol, no SDK.
DLD30T-5N Single-line TOF Measuring 2D LiDAR (30 m)
Palm-sized IP67 single-line TOF 2D LiDAR with 0.08° resolution and Ethernet point-cloud output for AGV navigation.
DLD50T8N / DLD50T8P — 50 m Measuring LiDAR with Discrete I/O + Ethernet
A 50 m TOF lidar with Ethernet point-cloud data and hard-wired NPN/PNP discrete output from one sensor.
DLDS2030A-5S Laser Scanning Radar
DLDS2030A-5S is the same 20 m 2D TOF obstacle-avoidance LiDAR as our DLD20A5 series, sold under an earlier model code. If you bought under this code, this is your unit — the specifications below are the DLD20A5 figures.
SDLD-05A TOF Laser Radar (Obstacle-Avoidance Type)
A 270° TOF laser radar with 0.1-14m range and 16 switchable zones for AGV/RGV obstacle avoidance.
ST27 Series Safety Laser Scanner (Type 3 ESPE, 3 m / 5 m Protective · 20 m Warning · 60 m Measuring)
A Type 3 safety laser scanner for machine builders and AGV/AMR integrators who must stop a machine when a person enters a hazardous area — it replaces fences and multiple light curtains with one 276° horizontal protective field of 3 m or 5 m, wired straight to a safety relay or safety PLC by OSSD.
Compare the Configuration Paths
| Required task | Existing product page | What to confirm |
|---|---|---|
| Personnel protective-field evaluation | ST27 protective-scanning configurations | Request exact model, protective-field limits, OSSD interface and applicable safety evidence. |
| Navigation and mapping data | DLD-50D navigation/measuring scanner | Select DLD-50DH/DC/DP for Ethernet measurement data; do not order it as an NPN/PNP switching scanner. Confirm exact scan settings, host software and target conditions. |
| Obstacle output and measurement requirements | DLD50T8N / DLD50T8P options | A different device from DLD-50D: choose the NPN (N) or PNP (P) version with Ethernet. Confirm output count, electrical rating and trigger logic; ordinary outputs are not safety OSSD. |
| Longer-range Ethernet measurement | DLD-100D variant comparison | DLD-100DP specifies fixed 100 Hz / 0.32°. For DH/DC, confirm the supported combination of the separately listed frequency and angular-step options. |
| DLD-50G project enquiry | DLD-50G model confirmation | Dedicated model evidence is still required for range, accuracy, scan angle, frequency and interface. Do not transfer DLD-50D or DLD50T8 specifications to this model. |
DLD-50D and DLD50T8 are different equipment, not interchangeable order codes. A shared download reference is not evidence of identical hardware, wiring or firmware; ask for documentation matching the quoted model.
A LiDAR Sample-Evaluation Request
| Purchase input | Information to provide |
|---|---|
| Target and working distance | Give the darkest expected target, minimum size, usable range and approach direction; do not quote only maximum catalogue distance. |
| Mounting and coverage | Include scan-plane height, blind areas, moving platform geometry and environmental exposure. |
| Controller handoff | List the required discrete signals or data interface and ask for the matching configuration tool and instructions. |
Use the 2D LiDAR selection guide to prepare the comparison, and the robot-cell sensor-role checklist when sensing and safeguarding share one cell.
Send the application details and required configuration through the inquiry form so that the quotation identifies the selected equipment and options.
