Safety Relay Modules for E-Stop, Light Curtain and Door Circuits

A safety relay module evaluates a dual-channel signal from an emergency-stop device, safety light curtain, safety door interlock or two-hand control and uses forcibly guided contacts to interrupt hazardous machine functions. It is the evaluation stage between the field safety device and the machine contactors — not the sensor, PLC or contactor itself.

Compare the DA31 e-stop safety relay with the DQSRN safety relay module by input type, contact arrangement and reset options.

Emergency stop light curtain or door interlock dual-channel input through a safety relay module to machine contactors and PLC status — Field safety device → dual-channel evaluation → forcibly guided contacts → machine contactors; status can be reported separately.

Compare 2 Safety Relays Series

DA31 Emergency-Stop Safety Relay Module

Ultra-slim 22.6 mm Category 4/PL e/SIL 3 safety relay with dual-channel PNP/NPN input and a solid-state status output.

DAIDISIKE DQSRN safety relay branding illustration, not a shipped-unit photograph or wiring reference

DQSRN Safety Relay Module

22.5 mm DIN-rail safety relay: dual-channel monitoring, manual or automatic reset, 3NO+1NC contacts and release response under 30 ms.

DA31 vs DQSRN Safety Relay Module

Compare the input/output options and circuit functions below. DQSRN supports manual or automatic reset according to the selected circuit, with a release response below 30 ms.

Published attribute	DA31	DQSRN
Housing width	22.6 mm	22.5 mm
Dual-channel input	PNP or NPN	see product input-mode specification
Input modes	e-stop / OSSD / door / two-hand	e-stop / OSSD / door / two-hand
Relay contacts	3 N.O. + 1 N.C. forcibly guided	3 N.O. + 1 N.C. forcibly guided
Separate PLC status output	transistor signaling output <500 mA / 24 VDC	not listed as a separate transistor output
Response	<30 ms	Release response <30 ms
Manual reset / automatic reset / EDM	Verify current DA31 circuit documentation	Manual/automatic reset per selected circuit; EDM not claimed

Select by Input Device and OSSD Compatibility

For an e-stop circuit, confirm that the device channels and selected relay input mode form the required safety function; the DA31 e-stop safety relay page contains its exact input and output selection. For an OSSD light curtain, choose the published OSSD input mode and verify output polarity and test-pulse compatibility from the exact device documents. For a guard switch, verify whether the field device outputs mechanical contacts, NPN or PNP transistor channels.

DA31 is also the catalogue option for a safety relay module with PLC status output: its separate transistor signaling output can report machine run/stop status to a PLC without consuming a safety contact. This is status reporting, not programmable safety logic. The DQSRN safety relay module is the alternative when its documented housing and terminal arrangement fit the panel.

What a Safety Relay Does — and Does Not Do

The relay evaluates the selected safety input and switches its safety contacts. It does not sense a person, read a door mechanically, or replace the output contactors. It also does not make the whole circuit Category 4 / PL e / SIL 3 by itself: the achieved level belongs to the complete safety function, including the input device, logic, output elements, architecture and validation.

Neither DA31 nor DQSRN is presented here as a programmable safety relay or safety PLC. If the application needs several independent zones, configurable logic or networked diagnostics, do not force a single-function relay into that role.

For a model check, send the field safety device, output type, required number of safety contacts, load/contactors and available DIN-rail width via the inquiry form.

Safety Evaluation or Programmable Process Control?

Keep the safety stop function separate from ordinary programmable automation. If the purchase is for timers, Modbus I/O or compact programmable sequencing, compare the relay and control module catalogue. Those modules are not substitutes for a safety relay or safety PLC.

For light-curtain pairing, use the light-curtain configuration guide to record the output version, then check the exact relay input documentation. Send the sensor code and controller requirement together rather than ordering each independently.

Frequently Asked Questions

What does a safety relay module do?

It evaluates a safety input and changes forcibly guided output contacts so downstream contactors can remove power from hazardous machine functions.

Which safety relay is suitable for a light curtain OSSD output?

DA31 and DQSRN both list an OSSD input mode. Confirm the exact light-curtain output polarity, test pulses and circuit documentation before final wiring.

Can DA31 send status to a PLC?

Yes. Its published specification includes a separate transistor signaling output below 500 mA / 24 VDC for status reporting.

Can DA31 execute configurable safety logic?

No. It uses DIP switches to select one of four published input modes; it is not presented as a programmable logic controller.

Do DA31 or DQSRN include manual reset, automatic reset or EDM?

DQSRN supports manual or automatic reset as described in the confirmed current instructions; follow the circuit for the selected module version. EDM is not claimed without explicit supporting documentation. For DA31, verify its own current circuit and mode information separately rather than transferring DQSRN functions.

Does a Cat.4 / PL e safety relay make the complete machine circuit PL e?

Not automatically. The complete safety function must be designed and validated to the required level, and its result is limited by the architecture and every component in the chain.

What is the main selection difference between DA31 and DQSRN?

Compare input type, contact arrangement, status output and circuit functions rather than housing width alone. DQSRN's current drawing specifies 22.5 mm, and its instructions describe manual/automatic reset by circuit. Use each module's own current dimensional and wiring document before panel layout.

Safety Relays in Action — 1 Demonstration Videos
