DLD-50D 2D TOF LiDAR for Navigation & Mapping (50 m)
50 m-range 2D TOF LiDAR for mobile robot navigation and mapping — ±20 mm repeatability, 280° FoV, Ethernet output.
🔍 Click to enlarge · 1/3Technical Specifications
| Model | DLD-50DH / DLD-50DC / DLD-50DP |
|---|---|
| Output | Ethernet 100BASE-TX (TCP data port 2368; UDP broadcast for device search/configuration); no NPN/PNP, relay, or analog output |
| Detection range | 0.1-50m @ 90% remission / 0.1-20m @ 10% remission |
| Repeatability | ±20mm |
| Scan angle (field of view) | 280° (80° blind sector: 320°-0°-40°) |
| Angular resolution | 0.08° / 0.16° / 0.32° (model-dependent) |
| Scan rate | DLD-50DH: 50Hz; DLD-50DP: 100Hz |
| Operating voltage | DC9-36V (typical 12V) |
| Power consumption | 2.5W |
| Laser | 905nm, Class I |
| Sampling rate | 225kHz |
| Ambient light immunity | >100000lx |
| Operating temperature | -10~55°C |
| Ingress protection | IP67 |
| Dimensions | 60×60×80mm |
| Weight | 250g |
| Default IP address | 10.10.10.121 |
| Software named in the DLD-50D manual | SimiView for parameter configuration and point-cloud viewing; DLD-50DSDK APIs for secondary development. Request version, package and host-compatibility details. |
| Safety classification | Measurement/perception LiDAR only — not a certified safety laser scanner (not intended for personnel safety functions per IEC 61496) |
| Detection accuracy | ±30mm |
Overview
The DLD-50D is a two-dimensional Time-of-Flight (TOF) LiDAR scanner that measures distance across a 280° plane and outputs point-cloud data over standard Ethernet (100BASE-TX). It is built for engineers developing mobile robots, AGVs/AMRs, and outdoor perception systems that need SLAM-grade localization data, contour/volume scanning, or wide-area object detection.
The series combines ±20 mm repeatability, a 280° field of view, and ambient light immunity above 100,000 lux in a 250 g, 2.5 W package that draws DC 9–36 V and reports data over Ethernet with a dedicated TCP data port. It is a measurement/perception LiDAR — not a certified safety laser scanner, and it is not intended for personnel safety functions under IEC 61496.
DLD-50D and DLD50T8 Are Different Devices
DLD-50D is the Ethernet measurement/navigation family on this page. DLD50T8N and DLD50T8P are separate measuring LiDAR devices with documented NPN/PNP output; they are not alternate names or interchangeable order codes for DLD-50D. Do not apply the DLD-50D manual, SDK, pinout or software assumptions to DLD50T8.
| Purchase check | DLD-50D on this page | Separate DLD50T8 family |
|---|---|---|
| Order codes | DLD-50DH / DLD-50DC / DLD-50DP | DLD50T8N / DLD50T8P |
| Documented interface | Ethernet 100BASE-TX; TCP measurement data on port 2368 | NPN or PNP plus Ethernet 100BASE-TX; application protocol needs confirmation |
| Measurement figures | ±20 mm repeatability; ±30 mm detection accuracy | ±30 mm accuracy; do not inherit DLD-50D repeatability |
| Software | SimiView and DLD-50DSDK named in the DLD-50D manual | Confirm the T8-specific software and protocol |
Compare the separate DLD50T8N/P product page if ordinary switching output is required.
Confirm Software and Supply Scope Before Ordering
- Provide the full DLD-50DH/DC/DP code, quantity, nearest/farthest targets, reflectivity or target sample, scan coverage and required update rate.
- State the host operating system, programming language and any ROS/ROS 2 requirement. Request written compatibility confirmation and the matching SDK/programming guide; naming an SDK does not prove those environments are supported.
- Ask the quotation to identify the software/SDK version, license conditions, cable and connector scope, mounting drawing revision, delivery destination and lead time. Included items and timing follow the quotation.
- Agree a sample test using known reference distances and the actual target. Check absolute error separately from repeat-reading variation, then verify scan data, host integration and blind-sector orientation.
Features & Benefits
±20 mm repeatability, distinct from ±30 mm detection accuracy
Repeatability describes consistency across repeated readings; detection accuracy describes error relative to the reference distance. Use the ±30 mm accuracy figure for an absolute-distance error budget, rather than treating ±20 mm repeatability as absolute accuracy.
Extra-wide 280° aperture with only an 80° rear blind sector
Wider than a conventional 270° scanner, giving fuller side coverage from a single mounting point — useful when mounting on a vehicle's front corner.
225 kHz ranging engine with model-specific angular resolution and scan rate
DLD-50DH offers selectable 0.08°/0.16°/0.32° angular resolution at 50 Hz for high point-density mapping; DLD-50DP runs 0.32° at 100 Hz for faster refresh in dynamic obstacle avoidance.
Ambient light immunity above 100,000 lux
The manual lists ambient light immunity above 100,000 lux. Confirm the actual target, sun direction and optical-window condition during an outdoor trial; this rating does not quantify performance in every outdoor scene.
Dual-rated range: 50 m at 90% remission and 20 m at 10% remission
The two reflectivity conditions help integrators compare the rated range against their actual targets. The 20 m figure is not an unconditional minimum across all dark surfaces or weather conditions.
IP67-rated housing for harsh environments
Sealed against dust and water ingress, suitable for outdoor and industrial deployment alongside the wide operating temperature range.
A 50 m-class scanner at just 250 g and 2.5 W
Compact 60×60×80 mm housing and low mass make it easy to integrate onto space- and weight-constrained mobile platforms; 2.5 W power draw and DC 9–36 V wide input suit battery-powered robots.
Ethernet output with SimiView and SDK documentation
Data is delivered over Ethernet 100BASE-TX (TCP data port 2368) with UDP broadcast for device search/configuration. The DLD-50D manual describes SimiView for parameter configuration and point-cloud viewing, and DLD-50DSDK APIs for custom integration. Request the applicable installer, SDK package and programming guide; supported operating systems, languages and ROS compatibility are not established by this manual.
Class 1 eye-safe 905 nm laser, −10 to +55 °C operating range
Suitable for continuous operation in occupied spaces, across a wide industrial temperature band.
Applications
Models & Ordering Information
DLD-50D series models (Ethernet output)
PDF & 3D CAD Downloads
Browse all downloadsDLD-50D User Manual - Shared 50 m LiDAR Reference
22 pages. The manual names DLD-50DH/DC/DP variants and is shared here as a reference for the listed 50 m products; it does not establish identical specifications for DLD-50G or DLD50T8N/P. Confirm the ordered interface, wiring and firmware before use. Some dimension-drawing labels remain in Chinese.
Confirm the document and CAD file match the exact ordered version before installation or mechanical design. Contact us if your model is not listed.
How to Select
- Choose DLD-50DH if point-cloud density matters most — it offers selectable 0.08°/0.16°/0.32° resolution at 50 Hz.
- Choose DLD-50DP if refresh speed matters most — it runs fixed 0.32° resolution at 100 Hz, better suited to fast control loops and dynamic obstacle avoidance.
- All three models (DLD-50DH / DLD-50DC / DLD-50DP) share the same Ethernet 100BASE-TX output with TCP data on port 2368 and UDP broadcast for device search/configuration.
- This series has no NPN/PNP, relay, or analog output — for hardwired I/O interlocking, select a different DAIDISIKE LiDAR model with NPN/PNP output.
- Compare the rated 20 m range at 10% remission with the actual dark target; the 50 m figure applies to 90% remission. Verify the required distance in the intended installation.
- If your application scans predominantly dark or low-reflectivity surfaces, plan for the 20 m detection envelope.
- All models share the 280° aperture with an 80° blind sector at 320°-0°-40° — orient mounting so the blind sector faces a direction with no required coverage.
📘 Need the full method? How to Choose a 2D LiDAR Scanner
When NOT to specify the DLD-50D — and what to use instead
Using DLD-50D as the protective device in a machine safety function
Why not: The DLD-50D specification states plainly that it is a measurement and perception LiDAR only, not a safety laser scanner, and not intended for personnel safety functions per IEC 61496. Its only output is Ethernet 100BASE-TX, with no OSSD.
Use instead: The DAIDISIKE ST27 Series Safety Laser Scanner — Type 3 / SIL 2 / Cat. 3 PL d, OSSD outputs, 3 m or 5 m protective field at 1.8% remission.
You need a hardwired NPN/PNP or relay output for a standard PLC input
Why not: The DLD-50D specification explicitly states there is no NPN/PNP, relay or analog output. The only output is Ethernet 100BASE-TX on TCP port 2368.
Use instead: For ordinary process control, compare a DAIDISIKE LiDAR documented with discrete output and confirm electrical compatibility. An Ethernet-to-I/O gateway does not turn this measurement LiDAR into a personnel-protection device.
Detecting dark or matte low-remission targets at long range, designing to the 50 m headline number
Why not: The 50 m range is rated at 90% target remission; the listed 10% remission range is 20 m. The reflectivity of an actual dark surface must be evaluated, not inferred from its colour alone.
Use instead: Design to the 20 m @10% remission figure for dark scenes, or ask us about a longer-range model if 20 m is not enough at the reflectivity you actually have.
You need full 360 degree coverage from one mounted unit
Why not: The documented scan aperture is 280 degrees, with an 80 degree blind sector spanning 320-0-40 degrees. It does not scan the full circle.
Use instead: Orient the mount so the blind sector faces a direction needing no coverage, or use DLD-100DC, which is documented with a full 360 degree scan.
You need both 0.08 degree resolution and a 100 Hz scan rate
Why not: Selectable 0.08/0.16/0.32 degree resolution is documented only for DLD-50DH at 50 Hz. The 100 Hz rate is documented only for DLD-50DP at a fixed 0.32 degree resolution.
Use instead: DLD-50DH for resolution-critical mapping; DLD-50DP for refresh-critical dynamic obstacle avoidance.
Site ambient below -10 or above 55 degrees C
Why not: The documented operating temperature range is -10 to 55 degrees C.
Use instead: Confirm ambient conditions against this range before installation, or contact us if the site falls outside it.
Specifications we do not publish yet
We only publish a figure once we are confident it is true. The items below are still being validated through further testing and real-world customer feedback, so for now we would rather leave them open than guess. If one of them matters to your design, ask us for the latest validated status.
- DLD-50DC scan-rate and angular-resolution settings, and any configuration-specific combinations beyond the published DLD-50DH and DLD-50DP figures.
- SDK-supported programming languages and operating systems, and whether a ROS driver is provided.
- Multi-echo capability and rain / fog / dust penetration performance — not documented for this model.
- Enclosure material.
- Certification numbers, issuing bodies and exact-model scope; request the applicable documents before committing a conformity requirement.
- Repeatability is ±20 mm and detection accuracy is ±30 mm — these are different measures and both are published. If your calculation needs one specifically, confirm which with us.
Frequently Asked Questions
What is the maximum detection range of the DLD-50D?
What is the field of view of the DLD-50D?
What angular resolution and scan rate does the DLD-50D support?
What is the repeatability (repeat accuracy) of the DLD-50D?
What data interface does the DLD-50D use?
Does the DLD-50D have NPN/PNP, relay, or analog outputs?
What software works with the DLD-50D?
Is the DLD-50D eye-safe?
Can the DLD-50D operate outdoors in bright sunlight?
Is the DLD-50D a safety-rated laser scanner?
What is the power requirement of the DLD-50D?
What are the dimensions and weight of the DLD-50D?
Can you provide certification documents for the DLD-50D?
Related Categories and Example Products
Explore other functions that may be needed in a machine or line. The products below are category examples, not pre-validated electrical or safety combinations. Confirm each interface and application separately: Relay & Timer Modules · Safety Light Curtains · Proximity Sensors
A1J0101 Economical Input Amplifier Module
Optocoupler-isolated input amplifier that turns a low-voltage signal into a 250V AC / 10A relay output.
DCE Automation Safety Light Curtain
Compact through-beam safety light curtain in a 30 x 30 mm housing: 10/20/30/40 mm beam pitch, up to 72 beams, 0.3-3 m or 0.3-6 m sensing distance, NPN/PNP output. Catalogue-stated Type 4 design basis; confirm exact safety-document scope.
D6.5 Series Inductive Proximity Sensors (Ultra-Short 18mm / Y-Type / 35mm / 45mm)
6.5mm-diameter inductive proximity sensors for tight-clearance mounting where M8 sensors won't fit.
Related Products in LiDAR Scanners
DLD-100D Single-Line TOF Scanning LiDAR
Single-line TOF scanning LiDAR with up to 100 m range, model-dependent 280°/360° coverage, and a 100 Hz / 0.32° DLD-100DP option.
DLD-50G 2D Single-line LiDAR (Diffuse-remission Measuring Type)
2D single-line laser scanner measuring diffuse-remission distance off natural surfaces, no reflector needed.
DLD05A3 2D TOF Obstacle-avoidance LiDAR (5 m)
2D TOF LiDAR with NPN/PNP switching outputs that wires like a photoelectric sensor — no protocol stack, no SDK.
DLD20A5-5N / DLD20A5-5P 2D TOF Obstacle-avoidance LiDAR (20 m)
